Fuan Double-Impeller Centrifugal Pump 2HCP140M
Fuan Double-Impeller Centrifugal Pump 2HCP140M
Call for Price
Fuan Pump
Website: www.fuanpumpbd.com
E-mail: fuan.nrs@gmail.com
Telephone: +880 2-41052919
Address: Holding Number 198-202, Nawabpur Road, Nawabpur Tower (1st Floor)Dhaka-1100, Bangladesh
Description
Fuan Double-Impeller Centrifugal Pump 2HCP140M
Application
Suitable for use with clean water and liquids that are not chemically aggressive towards the materials from which the pump is made.
The high efficiency and adaptability of these pumps to even the most unusual of applications, makes the ideal for use in the domestic, civil and industrial sectors, in particular for the distribution of water in combination with pressure sets, for pressure boosting and in fire-fightng sets.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※ Insulation Class B
※ Protection IP44
※ Continuous service S1
※ Thermal protector for single phase
※ Single-phase 220V/50Hz, 60Hz if request
Three-phase 380V/50Hz, 60Hz if request
Operating conditions
※ Liquid temperature up to 60℃
※ Ambient temperature up to 40℃
※ Total suction lift up to 8m
| Component | Construction |
|---|---|
| ※ Pump body: ※ Pump support: ※ Motor housing: ※ Impeller: ※ Motor shaft: ※ Mechanical seal: |
Cast iron Cast iron Aluminum Brass Carbon steel, AISI304 SS if request SIC/Graphite |
