Fuan Submersible Sewage Pump 100WQ5.5
Fuan Submersible Sewage Pump 100WQ5.5
Call for Price
Fuan Pump
Website: www.fuanpumpbd.com
E-mail: fuan.nrs@gmail.com
Telephone: +880 2-41052919
Address: Holding Number 198-202, Nawabpur Road, Nawabpur Tower (1st Floor)Dhaka-1100, Bangladesh
Description
Fuan Submersible Sewage Pump 100WQ5.5
Application
Suitable for use with dirty water that is not chemically aggressive towards the materials from which the pump is made.
As a result of their reliability and the fact that they are easy to use, and suitable for use in applications such as clearing dirty water, discharging domestic waste water, and for emptying collection traps containing partical up to a maximum ofφ100mm.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※ Insulation Class B
※ Protection IP68
※ Continuous service S1
※ Thermal protector for single phase
※ Single-phase 220V/50Hz, 60Hz if request
Three-phase 380V/50Hz, 60Hz if request
Operating conditions
※ 5m maximum immersion depth
※ Liquid temperature up to 35℃
※ Maximum ambient temperature 40℃
| Component | Construction |
|---|---|
| ※ Pump body: ※ Suction filter: ※ Impeller: ※ Motor shaft: ※ Mechanical seal:※ Cable: |
Cast iron Cast iron Cast iron AISI304 SS Alloy/Ceramic-Graphite SIC-SIC/Ceramic-Graphite(1HP, 1.5HP&2HP) 8m power cable |
Call for Price
Fuan Pump
Website: www.fuanpumpbd.com
E-mail: fuan.nrs@gmail.com
Telephone: +880 2-41052919
Address: Holding Number 198-202, Nawabpur Road, Nawabpur Tower (1st Floor)Dhaka-1100, Bangladesh
